Cutting Tools

Annular cutter or Trepanning cutter or Hole saw cutter or Core cutter are used to generate holes in any material. We offer these tools from size Ø20 mm up to 100 mm in different design like HSS, brazed carbide or indexable insert. Can be customized as per requirement.

Area of application :

• Cast Iron
• Mild steel sheet
• Stainless steel sheet
• Non ferrous material.

Back spot face cutter and back chamfer cutter cutter are used to generate spot face and chamfer which cannot be accessed from the front side. We offer these tools in various sizes in different material like HSS, brazed carbide or indexable insert. Can be used on drilling machine or milling machine or even VMCs.

Area of application :

• Cast Iron.
• Alloy Steel
• Stainless steel
• Non ferrous

Can be customized as per requirement.

We offer Circular blade and circular knife from diameter 40 mm up to diameter 550 mm in HSS, D2 steel or HcHcr depending on the application. The customized design blade can be manufactured to suit the application and the component work material.

Area of application :

• Packaging Industries
• Plastic Industries
• Rubber Industries

We offer high performance face mill cutter for Vertical Machining Centre, Horizontal Machining Centre of various capacities for machining of metal.

These cutters are particularly designed for obtaining :

• High production rates.
• Higher degree of consistency and accuracy in components.
• High degree of surface finish.

We offer these cutters in :

• Indexable insert face mill cutters.
• Brazed carbide face mill cutters.

These products are designed & manufactured to suit standard ISO inserts. All these cutters are designed to sustain stability at high machining parameters. Accordingly, the steel used are of high grade alloy steel duly heat treated and tempered, nitrided. Face mill cutters are dynamically balanced to give high surface finish & stability in dynamic conditions and heavy cutting load. All the cutting edges are maintained at equal heights on special machines to achieve uniform wear of carbide inserts, reduce vibration and load on the machine spindles.

We offer Gear Hob cutter and Gear Shaper cutter to generate gear tooth profile with different modules, pressure angle and class. Our tools are manufactured in various material like HSS- M2, M35, M42, ASP30, ASP52.

We can deliver Gear Hob from 0.5 module and above. Pressure Angle of 14.5 degree, 20 degree, 30 degree

We offer End mill cutter in HSS, Brazed carbide (TCT), Solid carbide and Indexable Insert type design. Our HSS cutter are made using M2, M35, M42 grade with systematic heat treatment process. We also provide thru coolant facility for hss, brazed carbide and tungsten carbide end mill.

Our range of size for end mill cutters are :

• Diameter 1 mm up to diameter 100 mm
• Flute length 20 mm up to 300 mm

These cutters are used on conventional or special purpose milling machines of various capacities to machine metal during manufacturing of dies & moulds, automobile components, etc.

We offer these cutters in:

• HSS (High Speed Steel) standard/special grade- M2, M35, M42, T42, ASP30, ASP52.
• Our Size range : Dia.60 to Dia.300 mm

These products are manufactured in various sizes and are tested for quality and duly heat treated. These tools are used for machining of deep slots, T slots, special profile, etc.

We offer HSS slitting saw cutter in M2 and M35 grade. Diameter range fro dia.40 mm up to dia. 600 mm. These products are manufactured in various thickness. As the name suggests, these tools are used for machining of thin slots from- 0.2mm up to 6 mm.

The different tooth profiles and number of teeth are made to suit different machining conditions. Tooth profile that can be generated are :

• A
• AW
• B
• BW
• C

Slitting saw cutters with radius profile, V profile or any other profile can be provided on request.

We offer disc type Spline cutter and Sprocket cutter to generate spline shaft and sprocket respectively. Our tools are manufactured in various material like HSS- M35, M42, ASP30, ASP52. These cutters are used by gear shaft and gear box manufacturers. We can also provide gauges for checking spline shaft.

We can manufacture cutters as per customer specification in ground and unground profiles.

We offer various types of dovetail cutter in HSS, HSS M35, Brazed carbide, Indexable Insert design. These tools are used on CNC, conventional or special purpose machines of various capacities for machining of metal.

We offer these cutters in 30 degree, 45 degree, 60 degree or custom made.

We offer Indexable insert shoulder mill and End mill cutter for VMC, HMC and conventional milling machine. Our cutters are manufactured to suit ISO standard and non standard tungsten carbide insert.

We offer indexable insert slitting or slotting cutter for VMC, Bed type boring machine and conventional or special purpose milling machines of various capacities.

We offer these cutters to suit tungsten carbide insert of customer choice in various thickness. Our range of size is from dia.40 mm up to dia.650 mm.

We offer indexable insert side and face cutter for VMC, HMC, Bed type milling machine and conventional or special purpose milling machines of various capacities.

We offer these cutters to suit tungsten carbide insert of customer choice. Our range of cutter size is from dia. 70 mm up to dia. 650 mm.

We offer Serration Hob cutter or Serration cutter in straight serration or helical serration. Our cutters are used to generate serrations on the jaws of lathe chuck and similar applications.

We offer :

• Serration metric pitch from 0.5 mm, 0.8 mm, 0.9 mm, 1 mm, 1.2 mm, 1.3 mm, 1.4 mm, 1.5 mm, 1.6 mm, 2 mm, 2.5 mm, 3 mm, 4 mm, 5 mm.
• Imperial pitch from 1/32”, 1/16”, 3/32”, 28 TPI, 20 TPI, 16 TPI, 15 TPI
• Serration angle 53 degree, 55 degree, 60 degree, 70 degree, 90 degree
• Diameter of cutter ranges from 50 mm up to 152 mm
• Length of the cutter ranges from 25 mm up to 300 mm

Our tools are manufactured in various material like HSS- M2, M35, M42, ASP2030, ASP52. Serration in ground profile can also be given upon customer requirement.

We offer T slot cutter and woodruff cutter for machining of ID groove for circlip or recess and woodruff key slot. Our tools are made using HSS or carbide in different grades as per application.

Our cutters are perfectly designed using optimal geometry to attain high cutting parameters and tool life.

We offer TCT slitting saw cutter in diameter range from dia.40 mm up to dia.600 mm. These products are manufactured in various thickness. As the name suggests, these tools are used for machining of thin slots from- 0.2mm up to 6 mm.

The different tooth profiles and number of teeth are made to suit different machining conditions. Tooth profile that can be generated are :

• A
• AW
• B
• BW
• C

Slitting saw cutters with radius profile, V profile or any other profile can be provided on request.

We offer Tungsten carbide slitting saw cutter in diameter range from dia.12 mm up to dia.180 mm. These products are manufactured in various thickness. As the name suggests, these tools are used on CNC machine for machining of thin slots from- 0.2mm up to 6 mm.

The different tooth profiles and number of teeth are made to suit different machining conditions. Tooth profile that can be generated are :

• A
• AW
• B
• BW
• C

Slitting saw cutters with radius profile, V profile or any other profile can be provided on request.
